Household electrical appliance powder coating(1)

Product series

---standard curing and low temperature curing products

---can be made of a variety of gloss and color products: specific glosss color to the user specified as the standard

--can be made of a variety of surface appearance of products: such as sand grain, continuous pattern, moire, imitation stone, metal effect etc.

Product characteristics

---no release of formaldehyde, does not produce harmful substances on the human body
---hardness is higher, the film is smooth. Not easy to scratch
---Daily chemicals，resistant performance, such as coffee, soap and water, vinegar etc.
---Impact resistance and other mechanical properties, good corrosion resistance

Product Detail

Product use

---Suitable for a variety of decorative products, such as: indoor household appliances, industrial equipment, lamps, etc..

Conditions of use
---coating thickness: in the use of 40-100 microns, the proposed film thickness of 60-80 microns
---average coverage: 10-12 square meters / kg, film thickness of 60-80 microns (to 100% usage)
---Baking curing conditions: recommended 200 degrees C/10 minutes, but also according to the user needs to design: 180 degrees C/15 minutes, 160 degrees C/20 minutes, 140 degrees C/30 minutes

physical property
---specific gravity: 1.5-1.8g/cm3 (due to different formulations and colors)
---Particle size distribution: the use of different types and different standards for the average particle size of 35-40 microns, less than 10 micron powder <10%, greater than 90 microns powder <0.5%.

Coating performance ---all tests were performed using 0.8mm film properties of cold rolled steel in thick oil and rust, the film thickness of 60-80 microns.

Product packaging
---carton packaging, lined with single layer thick film polyvinyl chloride plastic bags, net weight of 20 or 25kg

Storage condition
---the product should be stored in a dry, ventilated room at 35 degrees C, while avoiding direct sunlight. As in the air conditioning room storage, before use to powder at room temperature or with the same spraying equipment (temperature) storage, avoid damp. Under the above conditions, the powder can be stored stably for 12 months.
Note: for low temperature curing type and gloss in 40% (60 degrees) below the powder, storage temperature is less than 30 degrees

Health and safety

---Product raw material does not contain toxic substances, are in line with RoHS and reach, the baking free of toxic gases produced, but it should be avoided in the use of inhalation of dust in the process, the operator should wear a dust mask, and minimize the long-term exposure of skin and powder coating, attached to the skin of paint, can be washed with soap.
